The model MT160 is a digital ultrasonic thickness gauge. Based on the same operating principles as SONAR, the instrument is capable of measuring the thickness of various materials with accuracy as high as 0.1/0.01 millimeters. It is widely used in petroleum, chemical, metallurgy, shipbuilding, aviation, aerospace and other fields of production equipment, but also can be used for accurate measurement of various materials and various kinds of machining parts. Function & application Capable of performing measurements on a wide range of m aterial, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials. Transducer models are available for special application, including for coarse grain material and high temperature applications. Technical Specifications *Measuring range:0.75-300mm (Depends on probes) *Resolution：0.1/0.01mm *Accuracy:±0.05mm（≤10mm）;（±0.5%H+0.01）mm(>10mm); H refer to the thickness of workpiece *Working time：100h (EL backlight off). *Sound Velocity:1000~9999 m/s *Main unit weight：345g *Dimensions：150mm×74mm×32 mm *Power supply: two 5 (AA size) alkaline batteries（Battery not included in the package） *Communication storage：USB( USB communication cable is Optional Accessories) Working Conditions *Operating Temperature: －20℃～＋50℃ *Storage Temperature：-30℃～＋70℃ *Relative Humidity ≤90％ *The surrounding environment should avoid of vibration, strong magnetic field, corrosive medium and heavy dust. *Standard Accessories: Host, Standard ultrasonic thickness probe N05,ABS instrument case,Attached files
